 A comprehensive affordable LGS plugin for Sketchup. Draw and Generate CNC files for production.


Concrete meets bricks Light, white and tight scandinavian design White walls with designer chairs
Windows for the atrium Bedroom and office in one space Scandinavian design
×

Introduction.


Bridging the Gap Between Architects, Engineers and Frame Manufacturers.FrameBuilder-MRD Sketchup Add-on provides comprehensive design software and machine ready services for steel frame buildings and general LGS framing. With FrameBuilder-MRD and Sketchup, What you Draw is What you Get.

Key Features.


Draw Main Framing Components of any Light Gauge Steel Structure

Draw Wall, Trusses, Floor Joists

Produces Designs to manufacturing specification with all clearances taken into account

SSMA Structural Guidelines and Analysis

Real Time Costing of Frames

Generate full materials list and costing.

Export to Excel

Generate CNC files for product to be roll formed.

  • Month to Month
  • Full Features. Walls, Truss, Beam, Floors, CNC Generation and Costing
  • Email Support
  • Free Upgrade during period
  • $ 100

  • 1 Year
  • Full Features. Walls, Truss, Beam, Floors, CNC Generation and Costing
  • Email Support
  • Free Upgrade during period
  • $ 950

Demos.


More Demos

Download Free Trial.




Installation.



Prerequisites:
MS Windows 7+
Sketchup 2016+
Microsoft Excel 2010+
How to Install:
1. Install Sketchup. Make 2017(Free) 2018,2017,2016 Pro
https://www.sketchup.com/download/all
2. Download FrameBuilder-MRD Trial
3. Unzip FrameBuilder-MRD Zip
4. Install Sketchup Extension(unzipped FrameBuilder-MRD.rbz extension file) on 2016 and lower.
https://help.sketchup.com/en/article/38583
4.1 Install Sketchup Extension(unzipped FrameBuilder-MRD.rbz extension file) on 2017 and higher.
https://help.sketchup.com/en/article/3000264
5. Register when plugin loads on startup of Sketchup
6. Enter license key that was emailed.
rannumber3
